OneWire temperature and humidity sensor





General description of the sensor

The HS05045 is a digital temperature and humidity sensor using the OneWire technology.



The core of that sensor is composed of 2 sensors:



1) one DS18B20U based temperature sensor.



The main characteristics of that sensor are:

Temperature range -55°C to +125°C
Resolution 1/16 °C
Precision between -10°C and +85°C

±0,5°C as:

Precision between -55°C and +125°C ±2°C





2) one HIH4000 based humidity sensor.



The main characteristics of that sensor are:

Humidity range 0%RH to 100%RH
Resolution 1%RH
Temperature range of use -40°C to 85°C
Precision

±3.5%RH



Downloads

File

Content






Price

Description Reference

Price
One Wire temperature / humidity sensor HS05045 SFR 95.-- + SFR 1.-- for each meter of cable
